4720 01 296 0411 AN6270-4D1800 Hose Assembly King Air C90 GTiClick here to purchase or contact the seller of this item on eBay |
|
|
| Current Price: 25.00 USD |
AN6270-4D-1800
TUBE ASSEMBLY
NSN Number: 4720 01 296 0411
* Unit of Measure: EA
* Shelf Life: 72 Months
* ECCN: EAR99
* Weight: 0.15 Pounds
* Dimensions : 15’ (L)
DESCRIPTION
Military Standard Hose Assembly
* Recommended Use for Low Pressure Applications
* Detacheable Swivel Fitting
* Inner Diameter: 0.25 in.
* Outer Diameter: 0.5 in.
* Fitting Orientation: Straight to Straight
* Fitting Material: Aluminum Alloy
* A Side Nipple Type: 37 Degree Flared
* B Side Nipple Type: 37 Degree Flared
* Operating Pressure: 200 PSIG
* Proof Pressure: 400 PSIG
* Burst Pressure: 1250 PSIG
* Socket Threading: .4375-20 UNJF-3B
* Hose Length: 15 feet
* No Lockwire
* Industry Standard Specification: AN6270
Applicable Aircraft
Click on aircraft model to view serial range in Shop by Model.
* King Air C90GTi
* King Air C90GTx
* King Air C90GTx Fusion
|
|
|
|
|
|
|
